Outdoors Fill Flash - Sto-fen or Bare Flash?


Mr. ­ Blue
Senior Member
Avatar
365 posts
Joined Sep 2010
Location: Houston, Texas

Apr 01, 2011 22:02 |  #46

mgbeach wrote in post #913239 (external link)
I've got a shoot this weekend where I'm going to do a similar test to the one in my other post, but outside. Hopefully we'll put the issue to bed.

Kind of late to the party on this one, but was this ever done?


Gear
flickr (external link) | 500px (external link)
TheWitnessStudios.com (external link)


  LOG IN TO REPLY
gonzogolf
dumb remark memorialized
30,919 posts
Gallery: 561 photos
Best ofs: 2
Likes: 14915
Joined Dec 2006

Apr 01, 2011 22:09 |  #47

Mr. Blue wrote in post #12141699 (external link)
Kind of late to the party on this one, but was this ever done?

Its been done numerous times in other threads here. The results always show the stofen doesnt do anything significant.





  LOG IN TO REPLY
Mr. ­ Blue
Senior Member
Avatar
365 posts
Joined Sep 2010
Location: Houston, Texas

Apr 01, 2011 22:13 |  #48

gonzogolf wrote in post #12141732 (external link)
Its been done numerous times in other threads here. The results always show the stofen doesnt do anything significant.

I see. I have to admit that I didn't do any searching...this thread is the first one that popped up in my google search: "stofen omnibounce outside" :mrgreen:

Seems most of my questions have been answered by the google search > 1st hit POTN thread. Pretty cool actually.


Gear
flickr (external link) | 500px (external link)
TheWitnessStudios.com (external link)


  LOG IN TO REPLY
Wilt
Reader's Digest Condensed version of War and Peace [POTN Vol 1]
Avatar
46,487 posts
Gallery: 1 photo
Likes: 4580
Joined Aug 2005
Location: Belmont, CA

Apr 02, 2011 12:53 |  #49

The Stoffen reduces effectiveness of fill flash outdoors, in diminshing the contrast of shadows cast by the sun! This old (2008) test series should prove it to you.

First, sun only

IMAGE: http://i69.photobucket.com/albums/i63/wiltonw/IMG_1050-1.jpg

Next, straight fill flash (no modifier)
IMAGE: http://i69.photobucket.com/albums/i63/wiltonw/IMG_1052-3.jpg

Last, a Stoffen-sized 'diffuser'
IMAGE: http://i69.photobucket.com/albums/i63/wiltonw/IMG_1051-2.jpg


It is not larger than native flash lens as seen by subject (so no 'softer' in the shadows it might create); it sends light out in all directions (wasting light); and diminishes its intensity compared to bare flash (reduced its ability to reduce sun shadow contrast)

You need to give me OK to edit your image and repost! Keep POTN alive and well with member support https://photography-on-the.net/forum/donate.p​hp
Canon dSLR system, Olympus OM 35mm system, Bronica ETRSi 645 system, Horseman LS 4x5 system, Metz flashes, Dynalite studio lighting, and too many accessories to mention


  LOG IN TO REPLY
elguapo
Senior Member
348 posts
Joined Apr 2007
Location: Texas

Apr 02, 2011 17:10 |  #50

This is an interesting discussion. I've been reading up on diffusers and thought I would cast my vote on the side that says their usefulness is limited.

Here are a couple of things to keep in mind: 1). The larger the light source in relation to the subject, the softer the light will be. 2). Light can reflect (bounce off a surface), refract (change angles when going through a substance), or diffract (bend around an object or spread when passing through a small opening).

Based on the above, my understanding is that The Sto-Fen Omni-Bounce causes light to refract (go in different directions) because the light of the flash is passing through an opaque substance (plastic). Sto-Fen's website shows an illustration of this refraction at http://www.stofen.com/​info/howitworks.asp (external link).

The illustration on this page recommends pointing the flash with the Omni-Bounce at 45 degree angle to the subject, which will throw some of the light directly on the face to fill in shadows, and refract the rest if the light so that it reflects off the walls and goes back onto the subject. The light bouncing off the walls is now a large light source in relation to the subject and produces softer shadows.

The refraction interfering with the flash sensor probably also why Sto-Fen says to point the flash at a 45 degree angle:

Q: Why must I tilt the flash head to 45 degrees?

A: In Non TTL models this is necessary to avoid under exposure caused by light from the Omni hitting the external auto sensor of the flash. In TTL models it gives a better feathering wrap around of the light in the range from close to about 15 feet from the subject. Beyond that point with TTL we find straight on works OK for you.


The Gary Fong LS works the same way. If I had to guess, between the Omni-Bounce and the LS, I'd say the LS works better because is is bigger and causes more refraction. But it is also probably less efficient energy wise than the OB. But I don't know if the differences between the two are noticeable in either case.

With the Demb Bounce Card, the majority of the light from the flash is bounced off the ceiling while the bounce card reflects some light forward to the subject fill in the shadows under the eyes, nose and chin.

The cost of refraction is loss in efficiency. Sto-Fen's website (http://www.stofen.com/​info/faq.asp (external link)) says,

Q: What adjustments in exposure do I have to make using the Omni?

A:The only thing that happens with the Omni in place is the Maximum Distance of the flash is reduced by a factor of 2.5. For example if your Max Distance is 50 feet divided by 2.5 now equals 20 feet with the Omni in place.


Because the diffuser or direct flash is still lighting the face evenly, the lighting is flat, which is not the most interesting or flattering light for a subject.

The same results can be achieved as with a diffuser by bouncing the flash off a back wall. However, even more pleasing results can be achieved by bouncing the flash off a side wall or a reflector placed to the side of the subject. If there is nothing at all to bounce the flash off of sideways, and all you have is a ceiling, then perhaps the diffuser is useful in that scenario. But then again, if there are no side walls, then you don't have to worry about shadows with a direct flash, so why bother with a diffuser? Direct flash used correctly in that scenario (dialed down) will probably achieve the same results.

Outdoors, the only things a small diffuser will do is waste energy. Direct flash dialed down will achieve the same results more efficiently.

So why bother with soft boxes and umbrellas then? For two reasons:
1). Because the surface area of those items are much larger than the surface of the Sto-Fen, the light source is now larger in relation to the subject, which results in softer shadows.

2). Because you can use directional lighting with them. A flash placed at a 45 degree angle to the subject will produce more pleasing shadows than a flash pointing directly at the subject regardless of whether or not a diffuser is used.

Based on my currently level of understating, diffusers do produced better results indoors than what pointing a flash directly at someone will, but light bounced off a back wall will produce the same results for free. But light bounced off a side wall or object will produced even more pleasing results.

Outdoors, small diffusers do nothing but waste energy.

That said, if I am indoors and have no time to think about how I will bounce my flash, I'm slapping a diffuser on. A diffuser would also be useful if I have dialed my flash down as far as it will go and I am still over exposing a subject. In that case, a diffuser would help me reduce the light my flash is producing by about another stop.

I'm constantly learning, so the opinions I have now are subject to change.


Love without truth is hypocrisy; Truth without love is brutality.
