Is my lens bad or am I doing something wrong taking photos?


Ady2glude707
Member
39 posts
Joined Jun 2011

Aug 29, 2012 18:35 |  #1

Hello all,

When I shoot stationary objects, trees, building, etc, the pictures turn out fine. The examples shown below and in this album (external link) are pictures that didn't turn out sharp. Why is the couple in my photos blurry? They posed like statues but they are blurry. Am I using too large of an aperture? My shutter speed seems to be fast enough (some shutter speeds of 1/1000 or more were used (camera chosen). And I selected the focus point on my 60D as close to the subjects face as possible. For instance lets take the first and second picture as an example. On the first picture the focus point is on the female's right eye, however this picture is a little blurry. On the second picture the focus point is at the of the female's head, her hair and the photo is sharp. All photos are OOC jpgs. Please click here (external link) for the rest of the pictures where the subjects are blurry. What am I doing wrong?

Sharp
Focal Length: 30.0mm (35mm equivalent: 47mm...
Exposure Time: 0.0080 s (1/125)
Aperture: f/3.2

IMAGE: http://img.photobucket.com/albums/v132/ady2glude707/Sigma%2017-50mm/EOS_1223-1.jpg

Not Sharp
Focal Length: 30.0mm (35mm equivalent: 47mm...
Exposure Time: 0.0100 s (1/100)
Aperture: f/3.2
ISO Equiv.: 200
IMAGE: http://img.photobucket.com/albums/v132/ady2glude707/Sigma%2017-50mm/EOS_1224-1.jpg




  LOG IN TO REPLY
SoCalTiger
Goldmember
Avatar
1,748 posts
Gallery: 1 photo
Likes: 7
Joined Jul 2012
Location: SoCal

Aug 29, 2012 18:50 |  #2

I looked through a bunch of these pictures and my guess is that your lens is slightly back-focusing. I can't tell for sure due to the picture sizes but using this example it looks like the shrubbery just behind them is in focus but they are not:
http://smg.photobucket​.com …ew¤t=EOS_​1221-1.jpg (external link)

IMO, at your subject distance, I think your aperture should be fine. F/3.2 @ 30mm should be plenty enough DOF for what you are doing.

For the 60D, IIRC, all your focus points are cross-type. However, I believe the center point has the highest precision (F/2.8?). Have you tried using the center point only?


Laurence (external link) :: 6D + Lens


  LOG IN TO REPLY
Gatorboy
Goldmember
Avatar
2,483 posts
Likes: 2
Joined May 2005
Location: Bel Air, MD

Aug 29, 2012 18:52 |  #3

Ady2glude707 wrote in post #14923670 (external link)
All photos are OOC jpgs.

Digital images need to be edited in software. Apply USM and then determine if they are out of focus.

Also, 1/100 could be a bit slow for you to handhold steady.


Dave Hoffmann


  LOG IN TO REPLY
SoCalTiger
Goldmember
Avatar
1,748 posts
Gallery: 1 photo
Likes: 7
Joined Jul 2012
Location: SoCal

Aug 29, 2012 18:57 |  #4

Ady2glude707 wrote in post #14923670 (external link)
On the second picture the focus point is at the of the female's head

Oh, I just noticed this. You should always target a high contrast area to focus (eye usually works best). The forehead would generally lack contrast. You can see that the second photo of the two you posted is the more blurry one of the two.


Laurence (external link) :: 6D + Lens


  LOG IN TO REPLY
cfvisuals
Senior Member
866 posts
Joined Mar 2011
Location: San Diego

Aug 29, 2012 19:11 |  #5

Gatorboy wrote in post #14923768 (external link)
Also, 1/100 could be a bit slow for you to handhold steady.

Your photos are off focus, clearly.
We can see sharp background sharp hair splits / sharp shirt-sleeve. We can immediately eliminated hand shaky motion blur.
1/100s is for sure enough for 47mm equivalent focal length unless the handler has a shaky hand syndrome type of problem.

Like other said above, it's back-focusing. Some images are in focus. I am not exactly sure if it's an user error or lens problem. Cause it could be you, pointing at the wrong target and "misfocused". Or it could be the lens that is malfunctioning/miscali​brated.

I suggest you to do some scientific testing, use a tripod, get a stationary target and point at it. Open up your aperture all the way to the maximum.


flickr (external link)
5∞ portfolio (external link)


  LOG IN TO REPLY
MikeWa
Senior Member
Avatar
879 posts
Gallery: 89 photos
Likes: 235
Joined Apr 2012
Location: Seattle Washington

Aug 29, 2012 19:24 |  #6

Try f7. Shutter over 400. See what happens.
Good Luck
Mike


Mike...G9; 7D; 7D Mark II; EF-S 10-22mm; EF-S 18-135mm IS STM; EF 28-300mm F3.5-5.6L; EF 70-300mm IS USM; EF 70-200mm F2.8L IS-II; EF 100-400mm f4.5-5.6L IS; EXT 1.4-II & 2.0-III; The more I learn the less I know.


  LOG IN TO REPLY
watt100
Cream of the Crop
14,021 posts
Likes: 34
Joined Jun 2008

Aug 29, 2012 19:32 |  #7

Ady2glude707 wrote in post #14923670 (external link)
Hello all,

When I shoot stationary objects, trees, building, etc, the pictures turn out fine. The examples shown below and in this album (external link) are pictures that didn't turn out sharp. Why is the couple in my photos blurry? They posed like statues but they are blurry. Am I using too large of an aperture? My shutter speed seems to be fast enough (some shutter speeds of 1/1000 or more were used (camera chosen). And I selected the focus point on my 60D as close to the subjects face as possible. For instance lets take the first and second picture as an example. On the first picture the focus point is on the female's right eye, however this picture is a little blurry. On the second picture the focus point is at the of the female's head, her hair and the photo is sharp. All photos are OOC jpgs. Please click here (external link) for the rest of the pictures where the subjects are blurry. What am I doing wrong?

Sharp
Focal Length: 30.0mm (35mm equivalent: 47mm...
Exposure Time: 0.0080 s (1/125)
Aperture: f/3.2


Not Sharp
Focal Length: 30.0mm (35mm equivalent: 47mm...
Exposure Time: 0.0100 s (1/100)
Aperture: f/3.2
ISO Equiv.: 200


try using a higher aperture, for example f5.6 for a greater depth of field and use a higher shutter speed





  LOG IN TO REPLY
Earwax69
Goldmember
Avatar
1,044 posts
Likes: 4
Joined Jul 2012

Aug 29, 2012 19:44 |  #8

focus with the center point and recompose.

Also do some test with the lens to check if it back/front focus.


Canon 6D | S35mm f1.4 | 135mm f2 The rest: T3i, 20D, 15mm f2.8, 15-85mm, 24mm f2.8, 50mm f1.8, 85mm f1.8, 90mm f2.8 macro, 55-250mm.
So long and thanks for all the fish


  LOG IN TO REPLY
artyH
Goldmember
2,118 posts
Likes: 32
Joined Aug 2009

Aug 29, 2012 20:00 |  #9

An option is to focus with the center point only, and crop afterwards. Try using at least f4 or F 5.6. If you need to boost ISO to 320 or 400, then go for it. While 1/100 should be fast enough, you might try higher shutter speeds, like 1/160.





  LOG IN TO REPLY
RobDickinson
Goldmember
4,003 posts
Gallery: 14 photos
Best ofs: 4
Likes: 1053
Joined Apr 2010
Location: New Zealand

Aug 29, 2012 20:01 |  #10

Earwax69 wrote in post #14923977 (external link)
focus with the center point and recompose.

No, dont do this. Even at f3.2 that can cause some issues, select a focus point that matches where you want the focus to be.


www.HeroWorkshops.com (external link) - www.rjd.co.nz (external link) - www.zarphag.com (external link)
Gear: A7r, 6D, Irix 15mmf2.4 , canon 16-35f4L, Canon 24mm TS-E f3.5 mk2, Sigma 50mm art, 70-200f2.8L, 400L. Lee filters, iOptron IPano, Emotimo TB3, Markins, Feisol, Novoflex, Sirui. etc.


  LOG IN TO REPLY
Ady2glude707
THREAD ­ STARTER
Member
39 posts
Joined Jun 2011

Aug 29, 2012 20:24 |  #11

SoCalTiger wrote in post #14923760 (external link)
I looked through a bunch of these pictures and my guess is that your lens is slightly back-focusing. I can't tell for sure due to the picture sizes but using this example it looks like the shrubbery just behind them is in focus but they are not:
http://smg.photobucket​.com …ew¤t=EOS_​1221-1.jpg (external link)

IMO, at your subject distance, I think your aperture should be fine. F/3.2 @ 30mm should be plenty enough DOF for what you are doing.

For the 60D, IIRC, all your focus points are cross-type. However, I believe the center point has the highest precision (F/2.8?). Have you tried using the center point only?

Thanks for your reply. I do use the center point however in this situation I chose the focus point closest to the subjects face. I've read that choosing the focus point closest to the subject is better than recomposing a shot.





  LOG IN TO REPLY
NewEnglandPhotographer
Goldmember
2,343 posts
Likes: 5
Joined Feb 2011

Aug 29, 2012 20:28 |  #12

Gatorboy wrote in post #14923768 (external link)
Digital images need to be edited in software. Apply USM and then determine if they are out of focus.

Uhhh... what?!?! That is simply not true! If images SOOC are not sharp (assuming all settings are appropriate), something is wrong. The mindset that all images need to be edited in order to be sharp is just plain wrong.


Canon 7D | 70-200mm f2.8is II L | 24-70mm f2.8 L | 50mm f1.8 | 28mm f1.8 | Canon 1.4x TC II | 580EX II


  LOG IN TO REPLY
RobDickinson
Goldmember
4,003 posts
Gallery: 14 photos
Best ofs: 4
Likes: 1053
Joined Apr 2010
Location: New Zealand

Aug 29, 2012 20:42 |  #13

These are OOC jpg's and will have whatever sharpening is associated with the picture style already applied.

RAW needs some sharpening to combat the AA filter.


www.HeroWorkshops.com (external link) - www.rjd.co.nz (external link) - www.zarphag.com (external link)
Gear: A7r, 6D, Irix 15mmf2.4 , canon 16-35f4L, Canon 24mm TS-E f3.5 mk2, Sigma 50mm art, 70-200f2.8L, 400L. Lee filters, iOptron IPano, Emotimo TB3, Markins, Feisol, Novoflex, Sirui. etc.


  LOG IN TO REPLY
Sirrith
Cream of the Crop
10,545 posts
Gallery: 50 photos
Best ofs: 1
Likes: 36
Joined Nov 2010
Location: Hong Kong

Aug 30, 2012 03:15 |  #14

How long are you waiting after focus before pressing the shutter button? If you don't press it immediately when focus is achieved, it is possible you are swaying slightly and moving the plane of focus before actually taking the shot.


-Tom
Flickr (external link)
F-Stop Guru review | RRS BH-40 review


  LOG IN TO REPLY
Ramon-uk
Senior Member
834 posts
Gallery: 61 photos
Likes: 366
Joined Mar 2006
Location: Rochester UK

Aug 30, 2012 05:07 |  #15

Re focus using centre point and recompose

RobDickinson wrote in post #14924060 (external link)
No, dont do this. Even at f3.2 that can cause some issues, select a focus point that matches where you want the focus to be.

Complete rubbish, with a 30mm lens at f3.2 you have a DOF of more than 2ft.
You can focus and recompose quite safely.





  LOG IN TO REPLY
