Sharing a processing discovery


tzalman
Fatal attraction.
Avatar
13,497 posts
Likes: 213
Joined Apr 2005
Location: Gesher Haziv, Israel

Feb 03, 2013 07:10 |  #1

I'd like to tell you about a discovery I made yesterday. It won't be of much use to most members or for most photos, but it may be interesting for those who are interested in the more esoteric aspects of Raw processing.

First, a bit of background. When shooting landscapes and nature, including flowers, (in the Middle East it is already the beginning of Spring and the wild flowers are starting to bloom) I shoot with the camera set to the Uni-WB custom white balance. [For anyone not familiar with the term, the Uni-WB is a sort of anti-WB, a trick to prevent the camera from doing WB to the LCD jpg or the Live View display.]

Because the native, unbalanced color of a digital image has a strong green cast to it, the first step in my Lightroom workflow is to apply a WB in order to turn it into a more normal looking image. For this reason I have set up LR with an import preset that does nothing other than change WB from the default "As Shot" to "Auto", so on the computer I never see that green image and starting from "Auto" I tweak the WB to taste. But yesterday, while trying something unrelated to WB in DPP, I opened a shot of a red flower, shot with my 100 f/2.8L macro lens, in which the flower filled the entire frame - no other color there except various shades of red. And, of course, DPP opened it with the "As Shot" settings. The photo looked great, although in LR I had been having the problems that any shooter of red objects knows, WB often causes the red channel to clip in what seems at the time of shooting to be a properly exposed photo.

To confirm what I thought was happening, I opened the file in Raw Digger to see the Raw histogram. Normally, in a photo that contains a wide spectrum of colors, because the sensor is most sensitive to green, the green channel will be more exposed, i.e. more to the right, than the other two channels and one of the functions of white balancing is to beef up the relatively weak red channel. But in this case all the light reaching the camera was mostly red. There were still green and blue components in the light, but it was the red channel that was most exposed. I wasn't dealing with normal sunlight or any other "normal" lighting, and, therefore, WB not only wasn't needed, I was better off without it. I went back to LR and changed the WB to "As Shot" and was much more pleased with the rendering.

Of course this was a special case and few people will want to use the Uni-WB in their cameras. But I have noticed that in LR when it is set to "As Shot" the two WB sliders go over to the extreme left, 2000 and -150. I don't know if that really represents a null WB or the sliders just can't go any further left, but it does create a display that is quite close to what I see in a camera-created jpg with Uni-WB. So I'd advise that if you are in a similar situation, light that is strongly biased to one channel, almost mono-chromatic, try 2000/-150, you might like it.


IMAGE: http://photos.imageevent.com/elied/thisthatandtheotherthing/nature/_MG_9132.jpg

Elie / אלי


  LOG IN TO REPLY
tonylong
...winded
Avatar
54,657 posts
Gallery: 60 photos
Likes: 571
Joined Sep 2007
Location: Vancouver, WA USA

Feb 03, 2013 09:56 |  #2

Interesting, Elie!

But that was a real teaser about you guys experiencing "The beginning of Spring". Here in my area we are, well, not there yet!


Tony
Two Canon cameras (5DC, 30D), three Canon lenses (24-105, 100-400, 100mm macro)
Tony Long Photos on PBase (external link)
Wildlife project pics here (external link), Biking Photog shoots here (external link), "Suburbia" project here (external link)! Mount St. Helens, Mount Hood pics here (external link)


  LOG IN TO REPLY
kirkt
Cream of the Crop
6,602 posts
Gallery: 5 photos
Likes: 1556
Joined Feb 2008
Location: Philadelphia, PA USA

Feb 03, 2013 10:58 |  #3

Good observation. Unfortunately, in raw converters like LR/ACR, there is no way to directly adjust the WB multipliers for the R, G and B channels - in these applications, the preferred method of visualizing WB is with correlated color temperature and tint. So you sort of have to just slide the sliders and see what eventually gives you the result you want.

With other processors, the reduction or increase of the R, G and B multipliers is direct - in this case you can actually adjust the individual channels until you modify the overall WB to a point between desired look and no clipping.

It is, as you say, essentially exposing and balancing for one channel that is dominant compared to the others, and compared to the traditional assumption of green dominant.

Thanks for sharing! Care to make your raw file available to experiment with?

kirk


Kirk
---
images: http://kirkt.smugmug.c​om (external link)


  LOG IN TO REPLY
chauncey
Cream of the Crop
Avatar
9,696 posts
Gallery: 1 photo
Likes: 467
Joined Jun 2007
Location: MI/CO

Feb 03, 2013 11:27 as a reply to  @ kirkt's post |  #4

Damn Elie, I had to read that three time to understand what you were saying...and that was after I googled "Raw digger". :o
Regardless, in my case the question is moot as I either use a gray card or close my eyes and visualize what I want the colors to be. ;)


The things you do for yourself die with you, the things you do for others live forever.
A man's worth should be judged, not when he basks in the sun, but how he faces the storm.

My stuff...http://1x.com/member/c​hauncey43 (external link)


  LOG IN TO REPLY
tzalman
THREAD ­ STARTER
Fatal attraction.
Avatar
13,497 posts
Likes: 213
Joined Apr 2005
Location: Gesher Haziv, Israel

Feb 03, 2013 13:59 |  #5

kirkt wrote in post #15567504 (external link)
Thanks for sharing! Care to make your raw file available to experiment with?

kirk

No problemo.
http://imageevent.com/​elied/raw (external link)
Click on the thumbnail, select Original Raw CR2 at the bottom of the page, click Open High Resoution Raw and you should be asked if you want to open it or save it.


Elie / אלי


  LOG IN TO REPLY
kirkt
Cream of the Crop
6,602 posts
Gallery: 5 photos
Likes: 1556
Joined Feb 2008
Location: Philadelphia, PA USA

Feb 03, 2013 15:20 |  #6

Thanks Elie.

kirk


Kirk
---
images: http://kirkt.smugmug.c​om (external link)


  LOG IN TO REPLY
René ­ Damkot
Cream of the Crop
Avatar
39,856 posts
Likes: 8
Joined Feb 2005
Location: enschede, netherlands

Feb 04, 2013 16:48 |  #7

tzalman wrote in post #15566928 (external link)
the two WB sliders go over to the extreme left, 2000 and -150. I don't know if that really represents a null WB or the sliders just can't go any further left

The last I think.
If you want to go further, create a DNG profile, similar like you'd do for IR:
http://photo.tutsplus.​com …d-photography-processing/ (external link)


"I think the idea of art kills creativity" - Douglas Adams
Why Color Management.
Color Problems? Click here.
MySpace (external link)
Get Colormanaged (external link)
Twitter (external link)
PERSONAL MESSAGING REGARDING SELLING OR BUYING ITEMS WITH MEMBERS WHO HAVE NO POSTS IN FORUMS AND/OR WHO YOU DO NOT KNOW FROM FORUMS IS HEREBY DECLARED STRICTLY STUPID AND YOU WILL GET BURNED.


  LOG IN TO REPLY
