Please make an Educated guess about this Shot

i took with my 7D last saturday before my Camera went dead on Sunday saying the 6 Batteries were empty

EXIF data has been stripped, no way to tell your photo settings. Also what lens and was there a UV filter on it?

First things that come to mind:

- cheap UV?
- exposure leads me to believe you did not have an high enough ISO to allow for a fast enough shutter

But all speculation at this point with out any facts.

i used my 100-400mm,No Filter
ImageWidth - 5184
ImageLength - 3456
BitsPerSample - 8 8 8
Compression - 6 (JPG)
Make - Canon
Model - Canon EOS 7D
StripOffset - 58832
Orientation - Top left
StripByteCount - 2006066
XResolution - 72
YResolution - 72
ResolutionUnit - Inch
DateTime - 2009:06:26 08:07:23
Artist -
Copyright -
ExifOffset - 434
ExposureTime - 1/160 seconds
FNumber - 7.10
ExposureProgram - Shutter priority
ISOSpeedRatings - 160
ExifVersion - 0221
DateTimeOriginal - 2009:06:26 08:07:23
DateTimeDigitized - 2009:06:26 08:07:23
ComponentsConfiguratio​n - YCbCr
ShutterSpeedValue - 1/166 seconds
ApertureValue - F 7.03
ExposureBiasValue - 0.33
MeteringMode - Multi-segment
Flash - Flash not fired, compulsory flash mode
FocalLength - 400 mm
UserComment -
SubsecTime - 00
SubsecTimeOriginal - 00
SubsecTimeDigitized - 00
FlashPixVersion - 0100
ColorSpace - sRGB
ExifImageWidth - 5184
ExifImageHeight - 3456
InteroperabilityOffset - 46534
FocalPlaneXResolution - 5715.55
FocalPlaneYResolution - 5808.40
FocalPlaneResolutionUn​it - Inch
CustomRendered - Normal process
ExposureMode - Auto
White Balance - Auto
SceneCaptureType - Standard

GPS information: -
GPSVersionID - 2.2.0.0

Maker Note (Vendor): -
Macro mode - Normal
Self timer - Off
Quality - RAW
Flash mode - Not fired
Sequence mode - Single or Timer
Focus mode - AI Servo
Image size - Large
Easy shooting mode - Manual
Digital zoom - None
Contrast - High , +2
Saturation - High , +2
Sharpness - Low , -32769
ISO Value - 32767
Metering mode - Evaluative
Focus type - Auto
AF point selected -
Exposure mode - Tv-priority
Focal length - 100 - 400 mm (1 mm)
Flash activity - Not fired
Flash details -
Focus mode 2 - 65535
White Balance - Auto
Sequence number - 0
Flash bias - 0 EV
Subject Distance - 0
Image Type - Canon EOS 7D
Firmware Version - Firmware Version 1.2.1
Owner Name -
Camera Serial Number -
Sharpness (0D) - 49195
File number - 000 - 0000
Sharpness (A0) - 6

Thumbnail: -
JpegIFOffset - 48684
JpegIFByteCount - 10145

I don't think either a UV filter or shutter speed is causing the change about 1/3 down from the top of the photo. Something is wrong there. My first guess is the shutter, but I'm literally just guessing.

Tim

seems like there is definately some sort of software issue going on there... cant see how hardware (lens / filter etc...) could cause the line in the middle of the shot and cause it to not be lined up

Orogeny wrote in post #10470808
I don't think either a UV filter or shutter speed is causing the change about 1/3 down from the top of the photo. Something is wrong there. My first guess is the shutter, but I'm literally just guessing.

Tim

A shutter probably wouldn't cause a line that even and sharp nor the colour change; my first guess would be memory card and after that something electronic in the camera.

Foil wrote in post #10470798
i took with my 7D last saturday before my Camera went dead on Sunday saying the 6 Batteries were empty

i am reviewing the shots i took and something doesn`t seem right.My cam is on the way to the Service Center to solve the Power Supply Problem,might give them a Call if we Find a bigger Issue

My SWAG: Power fluctuation in the camera.

bfinta wrote in post #10470809
seems like there is definately some sort of software issue going on there... cant see how hardware (lens / filter etc...) could cause the line in the middle of the shot and cause it to not be lined up

I didn't see the line, oops. Yes, that looks more like a memory card issue, based on all the other memory card topics we have seen.

Shutter speed is too low though. ISO should be bumped to 400, and the shutter upped a bit more.

well i hope the problem is linked to the Power Supply and not linked to a CF card because i have 8 8Gb 60mb/s from Sandisk and 8 8Gb 90mb/s from Transcend,might be tough finding the culprit when i bear in mind that they all funtioned on my good old 40D i used as back up and my friends 7D when he ran out off cards

Foil wrote in post #10470832
well i hope the problem is linked to the Power Supply and not linked to a CF card because i have 8 8Gb 60mb/s from Sandisk and 8 8Gb 90mb/s from Transcend,might be tough finding the culprit when i bear in mind that they all funtioned on my good old 40D i used as back up and my friends 7D when he ran out off cards

Did you get the same results across multiple cards? Did you try to download the files via USB from the camera reading the card, versus plugging the card into a reader?

If you look to the right of the line... it looks like the lower part overlaps a photograph - strange indeed... good luck getting it fixed!

I have had similar effects from almost all of my bodies, and it always came down to a bad CF card. Every time I get these split-image issues it was always before a CF card crapped out on me. So far it's happened twice, and both times the card was the culprit.

I've also seen this issue come up from other people, and it's been related to reading/writing to the card, and an issue with the software in the body. I haven't had that type of problem yet, but I'm sure it can easily happen.


And yes, I've had CF cards go bad in my 40D. It happens unfortunately, sometimes they go bad. I had an 8 Gig Sandisk that gave me about 15 shots like yours in a matter of an hour or so, and not too long after that the card finally just stopped working. Couldn't retrieve photos (luckily at the time there weren't many on it), couldn't format it either in the camera or on the computer, it was dead. So I switched to another card and the problem was gone.

Hopefully it is related to the power issues. Losing power or shutting off power while writing to the card does weird things.

If not, it does look like a bad card. Try formatting.

Another reason why [edit] some pros prefer to shoot a 1D writing to both cards just in case. Don't want to lose shots from a paid shoot.

Card reader? Looks like corrupt image.

I also think is a card issue.
